Gr5 Titanium seamless pipe
Product name: Gr5 Titanium seamless pipe
Thickness: 0.1 mm to 100 mm
Origin: Baoji, Shaanxi, China
Size: OD 3 mm – 219 mm, Customized Sizes Available
Finish: Bright, Matte, Polished
Delivery status: M
Shape: Round pipe, square pipe
Certification: ISO9001:2015 GJB9001C-2017
standard: GB/T3624-2010, GB/T3625-2007, ASTM B337, ASTM B338
Applications: Aviation/Marine/Chemical/petroleum
Supply Ability: 300 Tons/month
Material Certification: MTC and SGS test reports available.
Product Introduction
Products Description
Gr5 Titanium seamless pipe is a weldless hollow pipe made of titanium or titanium alloy through a high-temperature and high-pressure forming process, which has excellent performance of high strength (tensile strength up to 140kgf/mm²), corrosion resistance (especially resistant to seawater and chloride environment) and high temperature resistance (some alloys still maintain plasticity at -253°C).
According to the type of titanium alloy structure, seamless pipes can be divided into three categories: α type (such as TA1, TA2), β type (such as TB2), and α+β type (such as TC4), which correspond to different strength and temperature resistance requirements. Its production process mainly includes hot extrusion, cold rolling, etc., with an outer diameter range of 6-80mm and a wall thickness of 0.5-4.5mm.
Titanium seamless pipes were initially used in aerospace engine components and have expanded into deep-sea oil pipelines, chemical equipment, medical implants, and more. For example, the hydraulic pipelines and deep-sea oil recovery platform pipelines of the Boeing 787 passenger aircraft are made of titanium seamless pipes, which are significantly better than traditional metal pipes in terms of weight reduction and long-term corrosion resistance. TSM is a leading manufacturer and supplier of different grades and sizes of titanium tubes, and its products comply with ASTM B338 and ASTM B861 standards. Grade 5 titanium seamless pipe (Ti-6Al-4V) is the most widely used titanium alloy pipe, its output accounts for almost half of all titanium alloy pipe production, contains 6% aluminum and 4% vanadium, belongs to (a+b) type titanium alloy, and has good comprehensive mechanical properties.
our products
Gr5Titanium seamless pipe supplier
China Gr5 titanium seamless pipe
Gr5 titanium seamless pipe manufacturing
Gr5 titanium seamless Parameter
|
Parameter |
Specification |
|
Material Grade |
Grade 5 (Ti-6Al-4V) |
|
Standards |
ASTM B338, ASME SB338, AMS |
|
Outside Diameter |
3 mm – 219 mm |
|
Wall Thickness |
0.1 mm – 100 mm |
|
Surface Finish |
Bright, Matte, Polished |
Mechanical Properties
|
Property |
Value |
|
Tensile Strength |
≥ 895 MPa ≥ 895 |
|
Yield Strength |
≥ 828 MPa ≥ 828 兆帕 |
|
Elongation |
≥ 10% |
|
Reduction of Area |
≥ 20% |
Key Features and Advantages
|
Feature |
Benefit |
|
High Strength-to-Weight Ratio |
It is 40% lighter than steel of the same strength, enabling designs with high weight requirements. |
|
Superior Corrosion Resistance |
It exhibits excellent resistance to brine, chlorides, and industrial chemicals. |
|
Excellent high temperature performance |
It can maintain its mechanical properties even at temperatures as high as 400°C. |
|
Biocompatibility |
Applicable to medical implants and surgical instruments |
|
Fatigue Resistance |
It exhibits excellent durability under cyclic loading conditions. |
Products Description
Mechanical Engineering
Parameters: TC21 titanium alloy pipe has a tensile strength of 1100MPa, an elongation strength of 1200MPa, and a density of 4.56 g/cm³; TA15 titanium alloy pipe is corrosion-resistant and high-temperature resistant, and can be customized.
Applications: Used in the manufacture of high-pressure resistant components, precision mechanical parts, etc.
Product: Seamless Titanium Tube TC21 Titanium Alloy Tube, High Strength, High Toughness, High Pressure Resistance, Cuttable
Aerospace
Features: TC4 titanium alloy pipe (Ti6Al4V) has high strength and light weight, making it suitable for aerospace structural components.
Applications: Rocket engine casings, satellite components, etc.
Products: TC4 seamless titanium pipes, TC4 titanium pipes, Ti6Al4V titanium alloy pipes, GR5 titanium pipes (customization available)
Petroleum and Chemical Industry
Corrosion resistance: TA2 titanium pipes have an extremely low corrosion rate in environments containing H2S/CO2^.
Applications: Oil well pipes, chemical reactors, seawater desalination equipment.
Products: TA2 titanium pipe, TC4 seamless titanium pipe, TA18T titanium A10 pipe, corrosion-resistant and lightweight, supplied by Ruida.
Medical field
Biocompatibility: The elastic modulus of TC4 titanium pipe is close to that of human bone, resulting in a low postoperative infection rate.
Applications: Artificial vertebrae, orthopedic implants, surgical instruments.
Other fields
Sports equipment: golf clubs, tennis rackets, etc.
Automotive industry: weight-reducing components, high-performance parts.
Application and use standards
Heat exchanger applications: Titanium pipes are widely used in shell and plate heat exchangers, including U-tube heat exchangers and straight tube heat exchangers.
Design standards: Controlled by TEMA standards, considering corrosion allowance, testing requirements, minimum thickness, etc., to design efficient solutions.
Structural features: The U-tube heat exchanger uses a fixed U-shaped tube, while the straight tubes are supported by a set of straight tubes.
Manufacturing requirements: Factors such as wall thickness, eccentricity, length and diameter tolerances must be considered.
We offer comprehensive customization services to meet your specific needs.
Cutting: Precisely cut to the required length.
Welding: Providing professional welding services for complex components.
Bending: Cold bending and hot bending capabilities.
Sizing: Custom diameters and wall thicknesses.
Finishing: Multiple surface treatment options.
Why choose us?
As a professional enterprise with over two decades of experience in the titanium materials industry, Mingjie Titanium Industry's core competitiveness lies in its comprehensive technological control throughout the entire process. From raw material selection to finished product delivery, we ensure precision and reliability at every stage. We have established a three-tiered quality control system, employing 12 rigorous processes including spectral testing and non-destructive testing to achieve zero-defect product delivery. Our customer repurchase rate reaches as high as 92%, demonstrating our trust in our quality.
Our company boasts a professional team led by highly skilled technical personnel, providing a one-stop service from material selection and customized processing to logistics and distribution, ensuring customers receive high-quality titanium products.
Choosing Mingjie Titanium Industry is not just choosing a supplier, but also choosing to work hand in hand with industry experts to create efficient and reliable titanium material solutions.
