Gr2 Titanium Sheet
Product name: Gr2 Titanium Sheet, ASTM B265 Titanium Sheet
Grade: Grade 2
Standard: ASTM B265
Thickness: 0.019"(0.5mm) - 0.187"(4.75mm)
Width: 39.370"(1000mm) - 78.740"(2000mm)
Length: ≤236.22"(6000mm)
Finish: Hot rolling, Cold rolling.
Surface: Polishing, Pickling, 2B.
Payment: T/T, L/C.
MOQ: 100kg
Note:We can also customize product dimensions according to customer requirements.
Product Introduction
What's Gr2 titanium sheet
The following is a display of titanium plates in our workshop
ASTM B265 Gr2 Titanium Plate (Grade 2 Titanium Plate) is a commercially available pure titanium material that meets ASTM Standard B265. And its titanium content is up to 99.6%.It has high strength, excellent ductility, excellent corrosion resistance, and low density. This material has become the most widely used materials in the industrial field with good weldability, formability, and processability.And also it is commonly used in the manufacture of heat exchangers, reactors, storage tanks, pipe liners, and other equipment. The comprehensive performance and competitive price of Gr2 titanium sheet makes it highly favored by customers.
Classification and parameters of different titanium plates
|
Product name |
Thickness(mm) |
Width(mm) |
Length(mm) |
|
Titanium Sheet
|
0.5-0.8 |
800 max, Ti 6Al-4V |
2000 max |
|
0.8-4 |
1000 max |
3000 max |
|
|
Titanium Plate
|
4-8 |
2000 max |
4000 max |
|
8-100 |
2500 max |
6000 max |
Chemical components of the Gr2 titanium sheet
|
Gr 2 |
N |
C |
H |
Fe |
O |
V |
Pa |
Mo |
Ni |
Ti |
||
|
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/
|
/ |
/ |
balanc2 |
Mechanical Property of the Gr2 titanium sheet
| Grade 2 |
Tensile strength(min) |
Yeild strength(min) |
Elongation(%) | ||
|
ksi |
MPa |
ksi |
MPa |
||
|
50 |
345 |
40 |
275 |
20 |
|
Testing Methods for Gr2 Titanium sheet
|
Category |
Testing Method |
|---|---|
| Chemical Composition | OES (Optical Emission Spectroscopy) |
|
XRF (X-ray fluorescence) |
|
|
ICP (Inductively Coupled Plasma) |
|
|
Mechanical testing |
Tensile test (tensile strength, yield strength, elongation) |
| Hardness test | |
|
Bending test (applicable to thin plates) |
|
|
Non-destructive testing (NDT) |
Ultrasonic testing (UT) |
|
Penetration testing (PT) |
|
|
Size inspection |
Thickness measurement (ultrasonic thickness gauge/micrometer) |
|
Width and length measurements |
|
|
Flatness check |
|
|
Surface inspection |
Visual inspection (ASTM standard) |
|
Surface roughness test |
Advantage of the ASTM B265 Gr2 Titanium Sheet
Excellent Corrosion Resistance
Titanium forms a dense TiO₂ film when it comes into contact with oxygen. It is highly corrosion resistant, prevents Cl⁻ penetration, and is suitable for acidic and alkaline environments. It is widely used in chemical, shipbuilding and papermaking industries.
High specific strength
High specific strength: Titanium has a density of 4.51 g/cm³, which is about 60% of that of steel.it can significantly reduce the weight of the structure while maintaining strength.
Good high temperature resistance
Excellent high temperature resistance: It can be used for a long time at high temperatures (the working temperature of titanium alloy can reach 400~600℃); it has a small coefficient of thermal expansion and good thermal stability.
Good processing performance
It can be cold-worked and hot-worked, and its cutting performance is superior to other difficult-to-machine metals; it also has excellent welding performance.
our inspections for gr2 titanium plate
Chemical composition analysis
In order to ensure the chemical composition of the titanium plate to meet the requirements of ASTM B265 standard,we give the chemical composition analysis of the titanium plate.
Mechanical property testing
including tensile strength, yield strength, elongation and other tests, to verify whether the mechanical properties of the material meet the standards.
Non-destructive testing
Ultrasonic testing, eddy current testing and other methods are used to conduct 100% inspection of the interior and surface of the titanium plate to ensure that there are no defects.
Dimension and appearance inspection
Measure the thickness, width, length and other dimensions, and check the surface quality to ensure that it meets the specifications.
Corrosion resistance assessment
The corrosion resistance of titanium plates under specific environments is evaluated through methods such as salt spray testing.
Service we supply
We also accept third-party inspection and welcome customers to arrange inspection in our workshop before shipment..
Manufacturing process
Baoji Mingjie Titanium Materials Technology Co., Ltd. specializes in titanium plate production. Our products meet international standards for medical and military applications, and our quality is ensured through comprehensive testing ,in this way to guarantee titanium stable performance. We have equipped with professional production equipment and also an experienced team with nearly 15 years.Our company maintains strict control over the production process,and meanwhile we offer significant price advantages and possessing complete certifications and qualifications to meet the needs of high-end applications.
01
High Quality
Titanium plate quality control: full-process testing, strict adherence to standards to ensure performance.
02
Advanced Equipment
Advanced titanium production equipment: vacuum melting to ensure purity, rolling mill, and support for non-standard customization.
03
Professional Team
Led by senior experts, all members possess industry backgrounds and registration qualifications, with experience covering multiple fields.
Custom Service
We are customer-centric, respond quickly to needs, solve problems professionally, and create value through dedicated service.
Our Certificate
Hot Tags: gr2 titanium sheet, China gr2 titanium sheet manufacturers, suppliers, factory, titanium plate fast shipping, titanium plate for sculpture, titanium plate for tanks, titanium plate surface treatment, titanium sheet for anti corrosion system, titanium sheet for prosthetics
